Custom Carbide Roller with Holder Assembly

The AstraRoll Custom Grooved Solid Tungsten Carbide Roller with Holder is a high‑precision rolling component designed explicitly for continuous cold‑ribbing operations for welded reinforcing mesh production, demanding consistent rib profile accuracy, high wear resistance and extended service life. Standard alloy‑steel rollers rapidly suffer from abrasive wear, groove deformation and dimensional deviation under repeated cold‑rolling loads for steel wire. This creates inconsistent rib geometry, poor concrete bonding performance and frequent roll change downtime.

AstraRoll’s monolithic solid tungsten carbide grooved rollers resolve these drawbacks by adopting vacuum‑sintered WC‑Co cemented carbide blanks, processed through multi‑stage CNC turning, cylindrical grinding and precision groove machining. The custom‑matched holder assembly provides rigid mounting and precise roller alignment for the roller body. Every grooved roller is precision‑machined with strict controls for groove profile, cylindricity and dimensional tolerance. It delivers stable rib forming performance and uniform transverse ribs for steel wire used in welded reinforcing mesh.

• Product Category: Custom Grooved Solid Tungsten Carbide Cold Ribbing Roller with Holder
• Roll Body Material: Premium cemented carbide WC‑Co (Grade selected according to rolling workload & steel wire material)
• Overall Dimension: Fully customized to match rolling mill stand size & rolling‑force requirements; OD 60–250 mm, Grooved Working Face Length 80–400 mm
• Groove Profile: Custom rib groove shape, pitch and depth per customer drawings Concentricity / Total Indicated Runout (TIR): ≤0.02 mm (Obtained by high‑precision CNC cylindrical grinding)
• Hardness: HRA 88‑92
• Manufacturing Process: Vacuum sintering, CNC turning, rough grinding, precision cylindrical grinding, custom grooving
• Holder Structure: Non‑standard design, fully pre‑machined per customer rolling mill drawings
• Inspection: 100% inspection of dimensions and groove profile before shipment
• Certification: ISO 9001

It delivers high‑hardness, wear‑resistant and dimensionally stable cold ribbing performance for welded reinforcing mesh production lines: Welded Reinforcing Mesh Manufacturing: Continuous cold rolling to form uniform transverse ribs on low‑carbon steel wire. Ribbed wire improves anchorage and bonding strength inside concrete for building slabs, flooring, road pavement and precast concrete components.

Expanded Application: Besides welded reinforcing mesh production, this grooved carbide roller can also perform cold ribbing or texturing on plain low‑carbon wire, galvanized steel wire, copper wire and aluminum wire. The ribbed wire is widely used in precast concrete components, plaster anti‑crack mesh, thermal insulation mesh and metal composite reinforcement projects. It is not recommended for high‑carbon spring wire or large hot‑rolled steel rebar.

We manufacture a full range of cemented carbide rollers and roll rings for diverse operating conditions, including:

• Solid tungsten carbide rollers for cold rolling, sizing, embossing and wire ribbing
• Tungsten carbide roll rings for two‑roll and three‑roll wire rolling mills
• Grooved rollers with custom rib profiles for reinforcing wire and welded reinforcing mesh production
• Annular grooved roll rings for wire diameter reduction, pre-forming and annular texturing
• Flat and special-profile rollers for custom metal wire and section forming

If you have special requirements for roller shape, groove geometry, material grade, size or mounting structure, please provide your technical drawings or process parameters for a customized solution.

Superior Wear‑Resistant Cemented‑Carbide Material Matrix: Conventional forged alloy‑steel rollers wear quickly under continuous high‑pressure cold rolling, leading to distorted rib profiles on steel wire. AstraRoll solid grooved rollers are manufactured from monolithic vacuum‑sintered WC‑Co carbide blanks. They provide outstanding wear resistance and rigidity under heavy rolling pressure, drastically extending service cycles and lowering roll change downtime.

Precision‑Machined Custom Groove Profile for Consistent Rib Geometry: Poorly controlled groove shape directly causes inconsistent rib height or width, reducing concrete anchoring effect. Our rollers are processed by dedicated CNC grooving equipment to lock groove geometry and dimensional consistency. Stable rib geometry ensures uniform quality of ribbed wire and finished welded reinforcing mesh.

Non‑Standard Custom Holder for Existing Rolling Mill Fit: Unlike standard universal brackets, our matched holder assembly is custom engineered strictly according to customer rolling mill drawings. It guarantees correct installation position, rigid bearing support and proper roller alignment for smooth continuous wire feeding.

Rigorous Full Inspection for Reliable Quality: Each roller undergoes 100% inspection of outer diameter, cylindricity, concentricity and groove profile before delivery. All rollers and holders can be fully customized according to mill parameters, rolling force and steel wire specifications.
