High Quality Steel Bar Electromagnetic Roller

Product Overview

AstraRoll‘s High Quality Steel Bar Electromagnetic Roller is engineered for the specified-length shearing production line in the metallurgy, bar material, and steel industry. Its primary function is to transport the steel bar and control the bar’s shearing length with precision. During cutting, the magnetic holding force prevents the bar from sliding or lifting at the tail end, enabling accurate automatic length setting.

The roller body is machined from carbon steel with a reinforced structure to withstand the radial loads and thermal exposure of continuous metallurgical operation. The internal field coil is arranged parallel to the roller axis, which generates a magnetic field perpendicular to the roller surface for uniform adsorption across the working face. Magnetization and demagnetization are controlled electrically, allowing the holding force to be engaged during conveying and released after the cut. The roller is typically supplied as a complete set with a rectification control cabinet and is designed for integration into new shearing lines or as a replacement for existing equipment.

Technical Parameter

• Product Name: High Quality Steel Bar Electromagnetic Roller
• Application: Specified-length shearing production line in metallurgy, bar material, and steel industry
• Core Function: Transporting steel bars and controlling shearing length; preventing bar slippage and tail lifting during cutting
• Roller Material: Carbon Steel
• Magnetic Source: Internal Electromagnetic Coil, parallel to roller axis
• Power Source: DC (Voltage customizable; standard models at 48V)
• Cold-State Power: Approx. 0.48kW – 1.03kW (Depending on Model and Magnetic Force)
• Magnetization/Demagnetization: Electrically Controlled
• Complete Set: Rectification Control Cabinet included
• Customization Scope: Roller diameter, face length, shaft configuration, magnetic force, voltage, and duty cycle
• Certification: ISO 9001 (Optional)

Application Industrial

Metallurgical Shearing Lines: Adsorption and controlled conveying of steel bars ahead of the shear for precise length control.

Steel Rolling Mills: Handling of bar layers in high-speed rolling and finishing lines.

Bar Finishing & Transfer: Transport of bars through cooling beds, inspection stations, and transfer points.

Why Choose AstraRoll’s High Quality Steel Bar Electromagnetic Roller?

Precise Shearing Length Control: The electromagnetic holding force keeps the bar firmly against the roller surface during conveying, preventing slippage and enabling accurate shearing length control.

Prevents Bar Lifting During Cutting: The magnetic field holds the bar down during the shear stroke, eliminating tail lifting and ensuring a clean, accurate cut.

Uniform Magnetic Field: The internal coil is arranged parallel to the roller axis, generating a stable magnetic field perpendicular to the working face for consistent adsorption.

Carbon Steel Construction: The roller body is machined from carbon steel for structural strength under continuous metallurgical loads.

Complete Set with Control Cabinet: Supplied with a rectification control cabinet for immediate integration into shearing lines.

Customizable Configuration: Roller diameter, face length, shaft configuration, magnetic force, and voltage are fully customizable to match specific line requirements.

Factory-Direct Supply & Long-Term Support: AstraRoll supplies electromagnetic rollers factory-direct, with strict quality inspection and long-term technical support.
